Description
Customizable Self Storage I Beam Building - Light Steel Structure Warehouse
KXD Steel offers efficient steel building solutions for manufacturing facilities. Our customizable steel manufacturing plant buildings are designed according to specific operational requirements, featuring clear span framing that maximizes usable square footage. These steel facilities provide the design flexibility needed for manufacturing success.
| Product Details | |
| Brand name | KXD STEEL STRUCTURE |
| Model | 1. Single slope, Double slope, Multi-slope. |
| 2. Single span, Double-span, Multi-span, Single floor, Double floors. | |
| Column and beam | 1.Material Q345(S355JR)or Q235(S235JR) steel. |
| 2. All bolts connecting. | |
| 3. Straight cross-section or Variable cross-section. | |
| Surface | Hot-dip galvanized or painted. |
| Roof and wall panel | 1.EPS ,PU , Rockwool sandwich panel. |
| 2.Single colorful corrugated steel sheet0.326~0.8mm thick, YX28-205-820(820mm wide). | |
| 3. Sandwich panel with EPS, ROCK WOOL, PU etc insulation thickness around 50mm~150mm, 950mm or 960mm width. | |
| Brace | X or V as well as other types of bracing made from angle, round pipe etc. |
| Accessories | Semi-transparent skylight belts, Ventilators, downpipe, outer gutter etc. |
| Window | PVC or Aluminum Alloy. |
| C or Z purlin | Size from C120~C320, Z100~Z200. |
| Door | Sliding or rolling up door. |
| Carrying capacity | 1.Resisting winds and seismic impacts. |
| 2.Bearing heavy snows. | |
| Drawing | 1.Making the design and quotation according to your requirements very soon. |
| 2.Making the quotation according to your drawings. | |
| 3.Giving you a satisfying opinion to your project. | |
| Certificate | ISO9001:2008, AWS certified welder passport,SGS,BV. |
